ICEMCFD Master Class (Level 2)

[LeeAndro]

MP4 | Video: h264, 1280x720 | Audio: AAC, 44.1 KHzLanguage: English | Size: 6.77 GB | Duration: 10h 12m

Perfect meshing for CFD

What you'll learn
Students will learn about creating high quality hexa meshing for CFD Analysis
Requirements
Basic knowledge of CFD and ICEMCFD
ICEMCFD installed on your computer, more preferably ICEMCFD 2020 R2 (ANSYS 2020 R2)
Description
Meshing is the most important part of any CFD process.

Meshing is the process to divide continuous domain in discrete parts known as control volumes. After discretizing, this mesh is provided to numerical (CFD) solver to solve algebraic equations arising from partial differential equations of continuous domain. Therefore meshing is most important part of any CFD process and accuracy & stability of CFD process largely depends on good quality mesh.

It is estimated that around 70% is spent on meshing in any CFD project. But after taking this course, you will be expert in meshing and you can generate meshes in very less than rest of CFD community.

In meshing you can either go with full hexa meshing or tetra meshing (with prism layers). Hexa meshing is more of an art and requires great deal of . But yields most accurate solution. It also requires less number of nodes and hence it require less compactional resources and less solution . It also avoids numerical errors /numerical diffusivity as you can observe in tetra meshes. It is estimated that tetra meshes requires as much as five s of mesh size as that of hexa meshing.

In this course you will enhance your ICEMCFD hexa meshing skills on more complicated geometries such as circular cylinder, 3D airfoils, stirred tank, wind turbine etc. Here you will each and every trick/tip of business of CFD meshing. After going through this course, you will be able to create perfect grid according to CFD simulation requirements and hence will be able to get most accurate results in less .

We will cover different topics as well which will increase effectiveness of hexa meshing.

Who this course is for
Students and professionals who strive to get best CFD results based on high quality meshing.
